IR Floodlight

   ◎ Stable photo cell control
   ◎ IR LED sensitivity variable through VR
   ◎ Aluminium body and high impact Poly Carbonate
   ◎ Power Source DC12V/AC24V/AC90~230V
   ◎ Cooling fan built in
   ◎ Long IR life time
   ◎ IP-66 rated

  ◎  IRL-107 / IRL-117 Series
  ◎ IR range @AES:300 meter(IR @15 degree) / 200 meter(IR @45 degree)

  ◎  IRL-401 series
  ◎ IR range @AES:200 meter(IR @15 degree) / 150 meter(IR @45 degree)

  ◎  IRL-601 series
  ◎ IR range @AES:250 meter(IR @15 degree)

  ◎  IRL-211 / IRL-221 Series
  ◎ IR range @AES:100 meter(IR @15 degree) / 80 meter(IR @30 degree)

IR Specifications

IR Wave Length


IR Radiation Angle

60Degrees  (blacke shell of the LED) or 45 degrees (white shell of the LED)

IR Life Time

20,000 Hours

R Control

Automatic Photo Cell Sensor

IR Sensitivity

Variable through VR (Select a timing to turn on or off)

Front and Rear Cover of Housing

High impact Poly Carbonate (Unbreakable)

Housing and Sunshield

Aluminum Alloy

Power Source

12V DC / 24V AC / 90V~260V AC


-10   50(14F~122F) /30   90 RH
